| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | FANRYN |
| إصدار الشهادات: | CE |
| رقم الموديل: | لوح من الصوف الصخري مع مواجهة رقائق الشب |
| الحد الأدنى لكمية: | 1 * 40HQ لكل المواصفات |
| الأسعار: | 0.2-5$/m2 |
| تفاصيل التغليف: | كيس من البلاستيك أو كيس تقلص PE |
| وقت التسليم: | 7-10 أيام |
| شروط الدفع: | تي/تي |
| القدرة على العرض: | 1 * 40HQ 7 أيام |
| توصيل حراري: | <=0.044 واط/م·ك | كثافة: | 40-200 كجم/م3 |
|---|---|---|---|
| التأثير البيئي: | قابلة لإعادة التدوير وصديقة للبيئة | مقاوم النار: | غير قابلة للاحتراق، الفئة A1 |
| الماءالامتصاص: | <1% | اسم المنتج: | صوف صخري للعزل الحراري |
| سماكة: | 30-100 ملم | مادة: | الصوف الصخري |
| قطر الألياف: | 7(+/-1)أم | محتوى اللقطة: | <= 12 ٪ |
| نقطة الانصهار: | > 1000 درجة | ||
| إبراز: | fireproof rock wool insulation panel,aluminum foil faced thermal insulation board,high density mineral wool curtain wall panel |
||
Products Description
FANRYN Rock Wool Boards are produced from inorganic raw materials, primarily basalt and limestone. The raw materials are melted in a cupola furnace at temperatures exceeding 1450°C. The resulting molten lava is subsequently fiberized through a high-speed centrifugal spinning process. These mineral fibers are then bonded with a thermosetting resin to form a cohesive and dimensionally stable product. Finally, the continuous mat is precisely cut into standardized board sizes to facilitate easy handling and installation on site.
Product parameter of the rockwool board
|
Properties |
Board |
Standards |
|
Density Tolerance |
±10% |
GB/T 19686-2005 |
|
Fire Performance |
Non-Combustible |
GB/T 5464-1999 |
|
Reaction to fire Class A1 |
GB/T 8624-2006 |
|
|
Thermal Conductivity (W/mK, at70±5℃) |
≤0.044 |
GB/T 10295 |
|
Fiber Diameter |
7(+/-1)um |
GB/T 5480. 4 |
|
Shot Content (shot size＞0.25mm) |
≤12% |
|
|
Moisture Content |
≤0.5% |
|
|
Organic Matter Content |
≤4% |
|
|
Melting Point |
＞1000℃ |
|
Product size of the rockwool board
|
Product |
Board |
|
Density (kg/m3) |
40-200 |
|
Size :L x W (mm) |
600X1200 |
|
Thickness (mm) |
30-100 |
Product feature of the rockwool board
Inherent Fire Safety: A1 non-combustible rating; does not burn, spread flames, or emit toxic smoke, providing critical passive fire protection.
Corrosion Resistance: Inorganic composition ensures it will not corrode metal substrates, guaranteeing long-term integrity.
Superior Thermal Insulation: Exceptionally low thermal conductivity minimizes heat transfer, leading to significant energy savings in heating and cooling.
Effective Acoustic Control: Porous, fibrous structure efficiently absorbs sound waves, reducing noise transmission and enhancing indoor acoustic comfort.
Hydrophobic & Moisture Resistant: Treated to repel water and resist moisture absorption, preventing mold growth and maintaining performance in humid conditions.
Excellent Dimensional Stability: High resistance to compression, sagging, and deformation ensures the board retains its shape, thickness, and R-value over time.
Energy Conservation & Carbon Reduction: Drastically lowers a building's operational energy demand, contributing directly to lower carbon emissions and lifecycle cost savings.
Eco-Conscious Material: Manufactured from abundant natural stone (basalt), supporting green building goals.
Product application of the Rock Wool Board
Building & Construction
External Wall Insulation: Enhances the building envelope for optimal thermal efficiency.
Roofing Systems: Provides insulation for both flat and pitched roofs.
Floating Floors: Effectively reduces impact sound transmission between floors.
Interior Partition Walls: Improves acoustic privacy and fire compartmentalization.
Industrial & Technical
Large-Diameter Pipeline Insulation: Ideal for insulating pipes in HVAC systems and industrial plants.
Production Facing For rockwool board
Aluminum foil facing
Fiberglass cloth
Production packing of the rockwool board
1. plastic bag
2. PE shrinking bag
FAQ:
Q1: How to guarantee the quality of the products?
A1: Our experienced QC team will inspect product's quality in every process
Q2: How to pack exported goods?
A2: Plastic bag (Standard Export Packing).
Q3: What is your lead time for one 40HCcontainer order?
A3: Usual 15-20 work days after placing order
Q4: What is your advantage on rock wool board?
A4: Special product with special specification can be made to order.
Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?
A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
