| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | fanryn |
| إصدار الشهادات: | GB/T 10294-1988 |
| رقم الموديل: | لوحة Glasswool |
| الحد الأدنى لكمية: | 1*40HQ |
| الأسعار: | 1-10$ |
| تفاصيل التغليف: | كيس بلاستيكي |
| وقت التسليم: | 7-10 أيام |
| شروط الدفع: | ر/ر |
| القدرة على العرض: | يمكننا إنهاء إنتاج 1*40HQ في حوالي 7-10 أيام |
| التأثير البيئي: | غير سامة وقابلة لإعادة التدوير | يكتب: | العزل الحراري |
|---|---|---|---|
| معدل الرطوبة: | أقل من 5 ٪ | كثافة: | 24-96 كجم/م 3 |
| معامل امتصاص الصوت: | 1.03 طريقة صدى المنتج 24 كجم/م 3 2000 هرتز | متانة: | طويل الأمد |
| الموصلية الحرارية: | 0.031-0.042 w/mk | المقاومة الكيميائية: | مقاومة لمعظم المواد الكيميائية |
| تطبيق: | السقف والجدار والعزل الأرضي | مقاومة الحريق: | الفئة A1 |
| مادة: | الصوف الزجاجي | استمارة: | ألياف |
| إبراز: | glass wool insulation board,thermal acoustic insulation board,mineral wool insulation with warranty |
||
Product Introduction Of The Glass Wool Board Insulation
FANRYN centrifugal glass wool board is a plate product with a fixed strength after hot-setting the centrifugal glass wool. lt has excellent thermal insulation performance at both high and low temperature environment. lt is mainly used for the separating wall in the high-grade building, ceiling, air conduit or inner wall of bellows for thermal insulation, or machine shops for noise absorption, or metal ceiling for control of moisture, High density panels with laminated facing can be used for air-conditioning duct system.
Product Parameter Of The Glass Wool Board Insulation
|
Technical Data |
|||
|
Item |
Unit |
Index |
Standard |
|
Density |
kg/m3 |
24-96 |
GB/T 5480.3 |
|
Average fiber dia |
μm |
5.5 |
GB/T 5480.4-1985 |
|
Water content |
% |
≤ 1 |
GB/T 3007-1982 |
|
Grade of combustibility |
|
Non-combustible Grade A |
GB 8624-1997 |
|
Preshrinking temp |
℃ |
≥250 |
GB/T 11835-1998 |
|
Thermal conductibility |
w/m·k |
0.031-0.042 |
GB/T 10294-1988 |
|
Hydrophobicity |
% |
≥ 98.2 |
GB/T 10299-1988 |
|
Moisture rate |
% |
≤ 5 |
GB/T 16401-1986 |
|
Sound absorption coefficient |
|
1.03 product reverberation method 24kg/m3 2000HZ |
GBJ 47-83 |
|
Slag inclusion content |
% |
≤ 0.3 |
|
Product Size Of The Glass Wool Board Insulation
|
Density(kg/m3) |
Thickness(m) |
Length (m) |
Width (m) |
Pcs/packing |
|
24-96 |
0.025-0.1 |
0.6-1.25 |
0.6 |
5-18 |
|
24-96 |
0.025-0.1 |
0.6-2.4 |
1.1-1.25 |
5-18 |
Product Feature And Application Of The Glass Wool Board Insulation
1. Heat preservation of wall
2. Heat preservation of steel structure
3. Indoor partition wall
4. Train compartment
5. Sound absorption and acoustical isolation
Production Details Of The Glass Wool Board Insulation
Product Packing Of The Glass Wool Board Insulation
The normal packing is plastic bag
OEM is acceptable
Production Facing Of The Glass Wool Board Insulation
1.Foil-Scrim-Kraft Facing
2.Alum Glass Cloth Facing
3.Fiberglass Tissue
FAQ:
Q1: How to guarantee the quality of the products?
A1: Our experienced QC team will inspect product's quality in every process
Q2: How to pack exported goods?
A2: Plastic bag (Standard Export Packing).
Q3: what is your lead time for one 40HC container order?
A3: Usual 7-10 work days after placing order
Q4: What is your advantage on glass wool board?
A4: Special size can be made according customer’s requirement.
Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?
A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
